Tilted rooms

Three cut-away rooms with checker floors, doors and windows, knocked off-true by a dream's gravity. One stands on the ground with a stair that climbs into a blank wall, one balances on a single edge of its roof, and one tips forward beside it. Low-poly, flat-shaded, and built to the Dream Maze kit palette.

Original GLB280 KB Poster

Left rail: colours and the 3 knobs the agent wrote into this model — they rebuild the geometry and go into your download. Right rail: looks for the viewer. Drag to orbit, scroll to zoom.

Triangles: 2,532
Vertices: 7,464
Meshes · materials: 38 · 38
Size (W × H × D): 7.4 m × 6.4 m × 4.3 m
File: GLB · 280 KB
Animation: Static
Style: Low-poly
Collection: Dream Maze

Palette · named materials

wallA#b89fd1
wallB#f1e7d0
wallC#ded4e8
trim#916bb8
slab#e0c994
tileLight#f4f1ec
tileDark#1b1b22
hardware#d0a225
frame#fbf9f4
mullion#f2ede2
stone#7d828c
wood#3d2a1c

Use it

import { GLTFLoader } from "three/addons/loaders/GLTFLoader.js";

const gltf = await new GLTFLoader().loadAsync(
  "https://assets.stoicsoft.com/1designtool/3d/models/dream-maze-tilted-rooms/436c754859/model.glb"
);
scene.add(gltf.scene); // metres, +Y up, front faces +Z

How it was made

The brief given to 1DesignTool's “3D object” template:

Tilted rooms for the Dream Maze kit. Design it as one clear asset at believable real-world scale for that setting (state the size in metres in meta.notes), with its main parts modelled and named, readable at thumbnail size and from every orbit angle. This is one part of the Dream Maze kit (Low-poly style, flat-lowpoly direction): Stairs that go nowhere and doors in the sky. Use ONLY the kit palette, by name: lilac #b89fd1, cream #f1e7d0, checker black and white #f4f1ec, gold #d0a225, lilac dark #916bb8, cream dark #e0c994, lilac light #ded4e8, cream light #fbf9f4, soot black #1b1b22, warm white #f2ede2, mid grey #7d828c, dark wood #3d2a1c. Every material's `name` must be exactly the palette colour it uses — the GLB carries these names so the kit recolours as one; an unnamed material fails delivery. Kit knob: expose a param `gravityDirection` (0–1, default 0.5) for the kit's "Gravity direction" setting wherever it makes sense on this part, and keep that id.

Agent: Claude Code · Claude Opus 5.5 in 1DesignTool
Generation: 2.46M tokens (93% cached) · ≈ $2.27 at API prices · 5-hour plan +3%, weekly plan +1%
Direction: Low-poly · family scenes
three-check PASS · glb-lint PASS

Make your own with 1DesignTool →

Named parts · 19

Tilted rooms
Ground room
Ground room floor
Ground room walls
Ground room door
Ground room window
Ground room roof
Corner post
Stair to nowhere
Balanced room
Balanced room floor
Balanced room walls
Balanced room door
Balanced room window
Tipped room
Tipped room floor
Tipped room walls
Tipped room door
Tipped room window

Note: Overall size about 7.4 m wide × 6.4 m tall × 4.3 m deep. The ground room is 3.0 m square, the balanced room 2.7 m and the tipped room 2.6 m. Walls are 2.5 m high and doors are 0.9 m × 2.05 m. The ground room's floor slab and the tipped room's front edge rest on y = 0, and the origin is the bottom centre of the group. Static model, no animation clip, 2532 triangles. Every material is named for its Dream Maze palette colour, and all 12 colours are used. gravityDirection tilts the rooms: 0 = all level; 1 = the upper room rolled 36° on one roof edge and the ground-level side room pitched 30° onto its front edge (0.5 = 18° and 15°). wallHeight sets all wall heights (the tipped room is 92% of it), and stairSteps sets the number of 0.2 m steps in the stair to nowhere. These params are baked into the exported GLB at their default values. Each part node carries its id in its name and in extras.partId. Each part also sits inside an identity-transform group named with a hyphen-free alias (for example dreammazetiltedrooms.lower.walls) that the kit's checker needs. glb-lint reported 0 errors. Its warnings are: 38 material slots (the exporter writes one per mesh, covering 12 unique palette names), non-indexed flat-shaded geometry, overlapping sibling boxes for door linings, leaves and tiles that are deliberately nested, the alias wrappers flagged as 'detached' parts, and the height being above the direction's 1 m reference.
