Văn Miếu – Quốc Tử Giám, Hà Nội

A tabletop diorama of the third courtyard of Hanoi's Temple of Literature: the Khuê Văn Các pavilion on four white pillars before the square Thiên Quang Tỉnh pond, flanked by the two doctoral stele halls sheltering rows of stone turtles carrying stelae.

Original GLB7.5 MB Poster

Văn Miếu – Quốc Tử Giám, Hà Nội 3D model

Left rail: colours and the 5 knobs the agent wrote into this model — they rebuild the geometry and go into your download. Right rail: looks for the viewer. Drag to orbit, scroll to zoom.

Triangles: 192,548
Vertices: 205,534
Meshes · materials: 72 · 12
Size (W × H × D): 88 cm × 26 cm × 1.1 m
File: GLB · 7.5 MB
Animation: scene-motion · 10.0s
Style: Product
Collection: Landmarks

Palette · named materials

plaster#ded8c6
ochreWall#c2a26b
redLacquer#7d3328
darkWood#4a352a
roofTile#59514a
stone#807a6d
brick#94553c
foliage#4d6b39
bark#57453a
water#3f5f53
ground#5e6c46
plinthMat#484e58

Use it

import { GLTFLoader } from "three/addons/loaders/GLTFLoader.js";

const gltf = await new GLTFLoader().loadAsync(
  "https://assets.stoicsoft.com/1designtool/3d/models/van-mieu-quoc-tu-giam/4457dfcc4e/model.glb"
);
scene.add(gltf.scene); // metres, +Y up, front faces +Z

const mixer = new THREE.AnimationMixer(gltf.scene);
gltf.animations.forEach((clip) => mixer.clipAction(clip).play());
// in your loop: mixer.update(delta)

How it was made

The brief given to 1DesignTool's “3D object” template:

The Temple of Literature (founded 1070), Vietnam's symbol of learning, as a diorama of its most famous court. Hero: Khuê Văn Các (Constellation of Literature Pavilion) — a small two-storey wooden pavilion raised on four square, white-plastered brick pillars; the square upper storey has a large round window on each side filled with a radiating sun-ray wooden lattice and red-lacquered wooden walls; a double-tiered roof of dark grey-brown yin-yang (âm dương) tiles with gently upturned corners and ridge ornaments. In front: Thiên Quang Tỉnh (Well of Heavenly Clarity), a large square pond edged with a low balustrade. Flanking the pond: the two long open stele houses with tiled roofs, sheltering rows of grey stone doctoral stelae, each stele carried on the back of a carved stone turtle. Old frangipani and banyan trees, brick-paved paths, weathered ochre-plastered boundary walls with a gateway. Loop (gentle, 10 s): soft ripples on the pond and a slight sway of the tree canopies. Make it a polished, elegant model in the stylised-PBR direction: clean proportions, smooth curvature, soft bevels on every edge, crisp silhouettes and a restrained palette of named materials (name each material for what it is, e.g. "limestone", "red lacquer", "glazed roof tile", "sea water"); every material in the exported GLB must carry that name — set `material.name` on each one, because an unnamed material fails review. It must be recognisable at a glance as the real place. No text, lettering, logos or signage anywhere. Reference photos of the real place are in `reference/` (ref1.jpg, ref2.jpg, ref3.jpg): open and study them before planning if you can view images, and compare your hero capture with them before delivering. Natural sites and large complexes are presented as a tabletop diorama on a clean rounded plinth with slate-grey sides; state the real-world scale and the diorama scale in meta.notes. Hard requirement: the exported GLB must contain AT LEAST 100,000 triangles (target 120,000–200,000) — measure it before delivering. Spend the budget on real modelled detail (roof tiles, carvings, railings, mouldings, rock strata, foliage clusters, water surface, boats), never on invisible subdivision. Keep the GLB under 20 MB: index all geometry, instance repeated parts, no image textures.

Agent: Devin · SWE-2 Max in 1DesignTool
Direction: Product · family scenes
three-check PASS · glb-lint PASS

Make your own with 1DesignTool →

Named parts · 40

Văn Miếu – Quốc Tử Giám diorama
Display plinth
Courtyard ground
Brick paths
Thiên Quang Tỉnh pond
Pond rim
Pond balustrade
Water
Ripple bands
Ripple 1
Ripple 2
Ripple 3
Lily pads
Khuê Văn Các
Stone platform
Four plastered pillars
Beam frieze
Upper storey and sun-ray windows
Balcony
Lower roof
Upper roof
West stele hall
West hall roof
Turtle-borne stelae, west
East stele hall
East hall roof
Turtle-borne stelae, east
Boundary walls
South gate
South gate roof
North gate
North gate roof
Old trees
Trunks
Tree canopies
Canopy 1
Canopy 2
Canopy 3
Canopy 4
Trimmed hedges

Note: The real courtyard is roughly 66 x 52 m; the diorama is modelled at 1:60 scale (real metres authored inside the root, scaled once), so the model stands 0.26 m tall on its plinth and spans about 0.87 x 1.1 m. Params rebuild geometry rather than just the viewer: treeCount and steleRows change the merged triangle count (192,548 tris at defaults, seed 7), and seed rearranges stelae, foliage and water ripples. The 10 s baked clip pulses three flattened ripple rings on the pond, bobs the water sheet, and sways each canopy about its trunk top. No image textures, no text.
