Kinh thành Huế, Thừa Thiên Huế

A stylised diorama of Ngọ Môn, with yellow and green glazed pavilion roofs above a five-gateway masonry base. Lotus ponds and a stone bridge complete the rear garden, with a gentle ten-second animated loop.

Original GLB8.6 MB Poster

Left rail: colours and the 3 knobs the agent wrote into this model — they rebuild the geometry and go into your download. Right rail: looks for the viewer. Drag to orbit, scroll to zoom.

Triangles: 347,552
Vertices: 272,122
Meshes · materials: 84 · 84
Size (W × H × D): 1.5 m × 42 cm × 1.1 m
File: GLB · 8.6 MB
Animation: scene-motion · 10.0s
Style: Product
Collection: Landmarks

Palette · named materials

slate#48545c
limestone#b1ada0
brick#866657
lacquer#87352e
wood#513d30
yellow#cda143
green#376b60
water#427c7b
lotus#63874e
petal#d9a9a2

Use it

import { GLTFLoader } from "three/addons/loaders/GLTFLoader.js";

const gltf = await new GLTFLoader().loadAsync(
  "https://assets.stoicsoft.com/1designtool/3d/models/kinh-thanh-hue/43b249b5ae/model.glb"
);
scene.add(gltf.scene); // metres, +Y up, front faces +Z

const mixer = new THREE.AnimationMixer(gltf.scene);
gltf.animations.forEach((clip) => mixer.clipAction(clip).play());
// in your loop: mixer.update(delta)

How it was made

The brief given to 1DesignTool's “3D object” template:

The Imperial City of Huế (UNESCO), seat of the Nguyễn dynasty, shown by Ngọ Môn (the Meridian Gate). A massive U-shaped stone-and-brick base about 58 m wide with five gateways (the central one for the emperor); on top, the Lầu Ngũ Phụng (Five Phoenix Pavilion) — a two-storey wooden structure on many red-lacquered columns with nine roofs: the central roofs in yellow glazed tiles, the side roofs in green-blue glazed tiles, all with upturned corners and dragon ridge ornaments. In front, a stone-paved esplanade; behind the gate, lotus ponds on both sides of a central causeway with a small bridge. Loop (10 s): lotus leaves sway and the ponds ripple. Make it a polished, elegant model in the stylised-PBR direction: clean proportions, smooth curvature, soft bevels on every edge, crisp silhouettes and a restrained palette of named materials (name each material for what it is, e.g. "limestone", "red lacquer", "glazed roof tile", "sea water"); every material in the exported GLB must carry that name — set `material.name` on each one, because an unnamed material fails review. It must be recognisable at a glance as the real place. No text, lettering, logos or signage anywhere. Reference photos of the real place are in `reference/` (ref1.jpg, ref2.jpg, ref3.jpg): open and study them before planning if you can view images, and compare your hero capture with them before delivering. Natural sites and large complexes are presented as a tabletop diorama on a clean rounded plinth with slate-grey sides; state the real-world scale and the diorama scale in meta.notes. Hard requirement: the exported GLB must contain AT LEAST 150,000 triangles (target 200,000–350,000) — measure it before delivering. Spend the budget on real modelled detail (roof tiles, carvings, railings, mouldings, rock strata, foliage clusters, water surface, boats), never on invisible subdivision. Keep the GLB under 25 MB: index all geometry, instance repeated parts, no image textures.

Agent: Codex · GPT-6.1-Sol in 1DesignTool
Generation: 2.58M tokens (96% cached) · weekly plan +0.37%
Direction: Product · family scenes
three-check PASS · glb-lint PASS

Make your own with 1DesignTool →

Named parts · 144

Ngọ Môn diorama
Slate plinth
Gate masonry
Five Phoenix Pavilion
Nine glazed roofs
Lotus ponds and causeway
Lotus cluster 1
Pond ripple
Lotus cluster 2
Lotus cluster 3
Lotus cluster 4
Lotus cluster 5
Lotus cluster 6
Lotus cluster 7
Pond ripple
Lotus cluster 8
Lotus cluster 9
Lotus cluster 10
Lotus cluster 11
Lotus cluster 12
Lotus cluster 13
Pond ripple
Lotus cluster 14
Lotus cluster 15
Lotus cluster 16
Lotus cluster 17
Lotus cluster 18
Lotus cluster 19
Pond ripple
Lotus cluster 20
Lotus cluster 21
Lotus cluster 22
Lotus cluster 23
Lotus cluster 24
Lotus cluster 25
Pond ripple
Lotus cluster 26
Lotus cluster 27
Lotus cluster 28
Lotus cluster 29
+104 more

Note: Tabletop diorama at 1:50: the approximately 58 m wide real gate is represented by a 1.16 m pavilion/base. Diorama plinth is 1.50 × 1.15 m, overall height 0.420 m; real architectural height is stylised at approximately 18.5 m above site grade. Metre units, +Y up, front +Z, underside at y=0. Simplified architectural reconstruction from supplied photographs, not a measured conservation survey. Nine roofs and five through passages; ornaments are stylised dragon silhouettes. Ripple rings and lotus leaves use baked rigid transform animation, not fluid simulation. Params rebuild the viewer; downloaded GLB contains the default settings. Parts use hue.* IDs because the kit validator requires an alphanumeric root; the library slug remains kinh-thanh-hue. Every exported material is named; runtime export duplicates some shared material records. Lint has nonblocking budget, nesting and lotus-clearance warnings. OBJ exports geometry only.
