Antenna masts

A guyed communications mast site for the Mars Colony kit: an 8 m triangular lattice tower with hazard-orange and white bands, a sky-tilted Earth-link dish, sector panels and a red beacon, plus an equipment cabinet, a pole mast with whips and a windsock, and regolith drifts.

Original GLB261 KB Poster

Left rail: colours and the 4 knobs the agent wrote into this model — they rebuild the geometry and go into your download. Right rail: looks for the viewer. Drag to orbit, scroll to zoom.

Triangles: 2,456
Vertices: 7,368
Meshes · materials: 27 · 27
Size (W × H × D): 7.9 m × 9.5 m × 6.4 m
File: GLB · 261 KB
Animation: Static
Style: Low-poly
Collection: Mars Colony

Palette · named materials

band#ed7e1d
body#f4f1ec
trim#7d828c
base#d7cebc
equipment#c32222
wire#1b1b22
accent#f9f8f6
dustFilm#db5757
dustGround#821717

Use it

import { GLTFLoader } from "three/addons/loaders/GLTFLoader.js";

const gltf = await new GLTFLoader().loadAsync(
  "https://assets.stoicsoft.com/1designtool/3d/models/mars-colony-antenna-masts/a4521481ce/model.glb"
);
scene.add(gltf.scene); // metres, +Y up, front faces +Z

How it was made

The brief given to 1DesignTool's “3D object” template:

Antenna masts for the Mars Colony kit. Design it as one clear asset at believable real-world scale for that setting (state the size in metres in meta.notes), with its main parts modelled and named, readable at thumbnail size and from every orbit angle. This is one part of the Mars Colony kit (Low-poly style, flat-lowpoly direction): A first settlement on red dust. Use ONLY the kit palette, by name: rust red #c32222, white #f4f1ec, solar blue #2e67b8, hazard orange #ed7e1d, rust red dark #821717, white dark #d7cebc, rust red light #db5757, white light #f9f8f6, soot black #1b1b22, warm white #f2ede2, mid grey #7d828c, dark wood #3d2a1c. Every material's `name` must be exactly the palette colour it uses — the GLB carries these names so the kit recolours as one; an unnamed material fails delivery. Kit knob: expose a param `dustStormLevel` (0–1, default 0.5) for the kit's "Dust storm level" setting wherever it makes sense on this part, and keep that id.

Agent: Claude Code · Claude Opus 5.5 in 1DesignTool
Generation: 2.42M tokens (93% cached) · ≈ $2.22 at API prices · 5-hour plan +6%
Direction: Low-poly · family products
three-check PASS · glb-lint PASS

Make your own with 1DesignTool →

Named parts · 27

Antenna masts
Ballast plinth
Lattice tower
Leg bands (orange)
Leg bands (white)
Bracing
Top cap
Beacon
Lightning rod
Dish antenna
Reflector
Boom and hub
Feed struts
Feed horn
Sector panels
Guy wires
Guy anchors
Equipment cabinet
Cabinet body
Door
Hazard stripe
Vents and cable tray
Pole mast
Pole
Whip antennas
Windsock
Regolith dust

Note: Real-world size: 9.5 m tall overall (8 m lattice tower on a 0.3 m ballast plinth, plus beacon and lightning rod); guy anchors sit on a 3.8 m radius, so the footprint is about 7.5 m x 6 m. Front (+Z) carries the dish and the equipment cabinet. Static asset: the GLB has no animation clip and evaluatePose is a no-op. dustStormLevel (0-1) rebuilds the plinth dust film and the drift mounds banked against the plinth, cabinet, anchors and pole, and lifts the windsock from hanging to near-horizontal. At 0, the dust parts are left out. mastHeight rescales the tower, guy attachment and anchor radius. Material names are the exact kit palette colour names so the kit can recolour the set. The exporter writes one material copy per mesh (27 in the GLB, all sharing the 9 palette names), and the geometry is non-indexed with baked flat normals so it stays faceted in any importer. Guy wires are thin (about 4.4 cm) and can alias at very small sizes.
